Non-rebated doors with hidden frame in wall 90 Right:
- opening to the outside
external dimension of the frame (mm) - 1009x2073
recommended mounting hole size - 1030x2085
- opening inwards
external dimension of the frame (mm) - 1009x2083
recommended mounting hole size - 1030x2095
panel door leaf with a thickness of 40 mm veneered with finish foil (colors in the further part of the offer)
magnetic lock. Choice of puncture: room key, bathroom lock, patent insert, savings lock (handle itself)
aluminium frame retractable in the wall Visio 40 primed white
Door frames available immediately. At the Customer's request, sending a package with a frame is possible on the next business day, and the door leaf at the latest on the declared date in the offer.
Door leaf construction:
The basis of the sash structure is a wooden frame, combined with cardboard filling in the form of a honeycomb. The sash is covered on both sides with foiled HDF board in the latest SOFT technology
Doors covered with foil are characterized by high resistance to mechanical damage as well as well tolerate the effects of moisture.
Frame hidden in the Visio 40 wall:
The Visio hidden door system allows you to achieve the effect of perfect flushing of the door with the wall. This is possible thanks to the use of special, hidden hinges. If you paint the door in the color of the wall, we will get the effect of continuity of the wall and door in the room. We offer a door frame for doors that are tilted inwards and outwards, right and left. The Visio door system is based on a universal, aluminum frame equipped with elements for precise assembly, powder coated, matching all mortise hinges available on the market. You can use a frame profile with or without a top beam (when the door is mounted to the ceiling itself).
Advantages of the Visio 40 hidden door system:
high stability and rigidity of the structure due to special profiles
reinforced corners of internal angles protect the structure at angular connections
wide range of application of the system up to 3 m of installation height and sash width of 1.2 m with a load of up to 100 kg
thanks to special frame profiles, the system works with most of the hinges available on the market
universal frame allows the system to be used for drywall and masonry walls
the possibility of painting the frame with wall paints thanks to the pre-coating with white primer paint
unique profile design avoids airbag effect
specially designed slot allows masking with glass or veneer, which increases the aesthetics of the finish
designed entrance to the angular mesh prevents cracking of the walls at the joints with the profile
no need for additional pads thanks to special fins to support each hinge
AVAILABLE OPENING DIRECTIONS:
PLEASE SEND A MESSAGE AFTER PURCHASE WITH THE SELECTED DIRECTION OF OPENING AND THE COLOR OF THE DOOR
